Spectra GM 34" Premium Radiator 4.8L, 5.3L, 6.0L, 6.2L, CU2423
Spectra GM 34" Premium Radiator 4.8L, 5.3L, 6.0L, 6.2L, CU2423
Regular price
$161.99
Regular price
Sale price
$161.99
Unit price
/
per
Spectra Premium Radiators are built to undertake the same durability and expectations of the OE.
Features & Benefits
- OE clevis pins are included, where required, to allow room for the occurring thermal expansion
- Stress cuts are made to the side rails to reduce stress on the headers and prevent warping during thermal expansion
- Increased tube wall thickness for durability and longevity
- Manufactured with high quality materials for extended durability
- Subject to aging and endurance testing to validate performance under extreme weather conditions
- Premium OE hardware and fittings included in every box
SPECTRA PREMIUM CU2423 Specifications | |
---|---|
Core Material | Aluminum |
Tank Material | Plastic |
Radiator Flow Type | Cross Flow |
Core Rows | 1 |
Core (IN) | 34-1/16 x 17-1/4 x 1 |
Inlet / Outlet Header (IN) | 18-7/16 x 3-1/8 |
Inlet / Outlet (IN) | 1-5/16 |
Mount Type | Top Flange / Bottom Pin |
Engine Oil Cooler Included | No |
Transmission Oil Cooler Included | Yes |
Transmission Oil Cooler Description | 5 Plates 11.5 in |
Transmission Oil Cooler Fitting Type | 5/8-18 UNF Female |
Cap Included | No |
Fan Included | No |
